Description
Description:
1.The production line adopts servo manipulator (optional ABB robot), grab feeding, improve production efficiency and automation procedures.
2.Of the production line feeding area can be connected with the front torsion bar equipment labeling equipment, carton output and subsequent strapping machine, packing machine and other equipment connected to form a complete automatic packaging production line.
3.The design structure of this machine meets the requirement of GMP standard and adopts PLC man-machine interface control.
.Adopt advanced servo intelligent drive, the main motor adopts frequency conversion speed control.
Packaging molding inspection, feeding, camera detection, lack of material testing, etc., to ensure the qualified rate of finished products.
4.Use safety cover protection device to ensure the safety of operators.
5.Packaging molding inspection, feeding, camera testing, lack of material testing, etc., to ensure the qualified rate of finished products.
6.Use safety cover protection device to ensure the safety of operators.
Technical parameters
| Max Output： | ≤300box/min ≤300 needle/min |
| Max Forming area and depth: | 245×130×30mm |
| Leaflet size : | （100-200）×（100-150）mm |
| Carton material: | 250-350g/m2 |
| Carton Size: | （65-200）×（25-85）×（15-60）mm |
| Leaflet material: | 50-70g/m2 |
| Air compressor | 0.6-0.8/Mpa≥0.8m3/min |
| Power | 380V 50HZ 8Kw(220V, 60Hz) |
| Weight | 4000kg |
